YM24 RJ45 Waterproof Connector Plug Front Panel Mount Ethernet RJ45 Socket Connector

Place of Origin : Guangdong, China

Brand Name : CNLINKO

Model Number : YM-24-C/RJ45/015/PE-42-001

Certification : UL,CE,ROHS,CCC,ISO9001

MOQ : 2

Price : $6.70-7.70

Type : RJ45

Application : Signal

Gender : male and female, Female +male

Protection level : IP65/IP67

Pin : 8pin

Connector type : RJ45

Shell & Insulated Parts : High Performance Engineer Plastic

Hardware Matel : Zinc Alloy (pearl hard chromium)

Connecting mode : plug/unplug

Package : Carton

Contact Now

Factory Price Cnlinko Waterproof Male Female Ethernet Connector lan RJ45 ethernet connector

Product Description

YM24 RJ45 Waterproof Connector Plug Front Panel Mount Ethernet RJ45 Socket ConnectorYM24 RJ45 Waterproof Connector Plug Front Panel Mount Ethernet RJ45 Socket ConnectorYM24 RJ45 Waterproof Connector Plug Front Panel Mount Ethernet RJ45 Socket ConnectorYM24 RJ45 Waterproof Connector Plug Front Panel Mount Ethernet RJ45 Socket ConnectorYM24 RJ45 Waterproof Connector Plug Front Panel Mount Ethernet RJ45 Socket ConnectorYM24 RJ45 Waterproof Connector Plug Front Panel Mount Ethernet RJ45 Socket ConnectorYM24 RJ45 Waterproof Connector Plug Front Panel Mount Ethernet RJ45 Socket Connector

Specifications
Specifications
Connecting mode Latching Lock connect
Protection level IP65/IP67
Cable specification 26-24AWG
Diameter range Φ5mm ~Φ6.5mm
Contact diameter×Qty 8PIN
Current rating(A) /
Temperature rise

/
Operating voltage(AC.V.rms) /
Withstanding voltage(AC.V)1min /
Contact resistance <30mΩ
Insulation resistance >500MΩ
Durability ≥500 mating&unmating cycles
Temperature rating -40°C~80°C
Method of connecting cable Soldering
Prevent the combustion level UL94-V0
Material
shell & Insulated parts High performance engineering plastics
Hardware metal Zinc alloy(pearl hard chromium)
Contact pin Copper alloy(gold-plated 4U)
Spring Stainless steel
Sealing Silica gel
Main characteristics
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
socket with cover
Application industries
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Ship equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery
